Diagram

Elements

CheckSteadyState
References Notes

In some file transfer scenarios the recipient of a file does not know when the sender creates the file. In case of (very) large files the recipient may try to read the file before the sender has finished writing it. This can result in the recipient retrieving an incomplete file.

Including the CheckSteadyState parameter ensures that the file is checked at its reception point for completeness before starting the transfer.

Including the CheckSteadyState parameter ensures that the file is checked at its reception point for completeness before starting the transfer.

If the check of the steady state of one incoming file did not succeed successfully then no file will be transferred.

Note that this is not a very reliable approach as the recipient checks the date of last modification and the size of the file. If neither changes during a specified a period of time then the file is assumed to be complete. However, if transmission is terminated without the file being completely written, the network goes down or the processing speed of the file is slow, then the receiver will get a corrupted file.

The shorter the check interval is chosen the more likely it may happen that a file is detected as steady, although this was not yet finished writing.

Element Type Required Description
CheckSteadyStateInterval int
  • Pattern: [\-+]?[0-9]+
  • Whitespace: collapse
  • Occurrence: 0..1
Optional
References Notes

The interval in seconds for checking the steady state of incoming files.

CheckSteadyStateCount int
  • Pattern: [\-+]?[0-9]+
  • Whitespace: collapse
  • Occurrence: 0..1
Optional
References Notes

The number of tries to check the steady state of incoming files.

CheckSteadyStateErrorState string
  • Min: 1
  • Whitespace: preserve
  • Occurrence: 0..1
Optional
References Notes

The next state in a job chain that is used if the check of the steady state of incoming files did not succeed successfully.

This parameter is only available if YADE runs as a JobScheduler job.
